The pre-embedded fiber in the ferrule of field assembly optical connector has already been pre-polished at the patchcord workshop. Just strip, cleave and clean the fiber and then insert the fixed-length fiber and connect with the pre-embedded fiber by index-matching gel.
1. Push-tight structure of fiber fastening, high precision of fiber connection;
2. Integral structure, simple structure, high stability and reliability, low cost;
3. Small size, suitable for narrow space environment;
4. Tail is screw type, excellent tensile strength,> 40N / 2min;
5. Easy to operate, fast to assemble, high success rate, long time of using, easy maintenance.
| Connector | SC/UPC | SC/APC |
| Model | FTB-SC-UPC-01 | FTB-SC-APC-01 |
| Insertion Loss | ≤0.25dB | ≤0.3dB |
| Return Loss | ≥50dB | ≥55dB |
| Applicable Cable | 2*3mm FTTH Drop Cable | |
| Tensile Strength | ＞40N/2min |
| Operating Temperature | -40C~+85C |
| Repeatability | ≤0.2dB |
| Repeated assembly | ≥10 times |
| Mate and demate | ≥500 times |
| Dimension | 50.3 x 9.8 x 9.8mm |
