| Fiber Count | |
|---|---|
| Fiber Type |
Adopted to backbone network, access network and fiber to the home.
|
|
G.655 |
50/125μm OM2 |
62.5/125μm |
||
|
Attenuation (+20℃) |
@850nm |
|
|
≤3.0 dB/km |
≤3.0 dB/km |
|
@1300nm |
|
|
≤1.0 dB/km |
≤1.0 dB/km |
|
|
@1310nm |
≤0.36 dB/km |
≤0.40 dB/km |
|
|
|
|
@1550nm |
≤0.22 dB/km |
≤0.23dB/km |
|
|
|
|
Bandwidth (Class A) |
@850nm |
|
|
≥500 MHz·km |
≥200 MHz·km |
|
@1300nm |
|
|
≥1000 MHz·km |
≥600 MHz·km |
|
|
Numerical Aperture |
|
|
0.200±0.015NA |
0.275±0.015NA |
|
|
Cable Cut-off Wavelength |
≤1260nm |
≤1480nm |
|
|
|
| Cable Type | Fiber Count | Cable Diameter mm | Tensile Strength Long/Short Term N | Crush Resistanse Long/Short Term N/100mm |
Bending Radius Static/Dynamic mm |
|
| JET 2~12 | 2~12 | 6.0±0.2 | 30 | 150/300 | 200/500 | 15D/30D |
Storage/Operating Temperature : -40℃ to + 70℃
Standard length:1000m;Other length availabe
