FIBERFUTURE® Anti-rodent ADSS cable is designed to protect cable against bite by using high strength glass fiber FRP. It has the advantage of smaller fiber core and stronger outer sheath which help guarantee communications ability and anti-bite capacity. The cable is made of non-metallic material and self-supporting with the aerial power transmission line.
| Fiber Count | |
|---|---|
| Fiber Type |
High strength glass fiber Strong elasticity modulus Small thermal expansion coefficient ALL-dielectric structure Free from high voltage and lightning
| 01 - Blue | 02 - Orange | 03 - Green |
| 04 - Brown | 05 - Slate | 06 - White |
| 07 - Red | 08 - Black | 09 - Yellow |
| 10 - Violet | 11 - Pink | 12 - Aqua |
| Items | Condition | Value |
| Fiber count | - | 2 to 144 core |
| Max. tensile strength (N) | Short term | As per requested |
| Long term | As per requested | |
| Max. crush strength (N/mm) | Short term | 3000 /2200 |
| Long term | 1000 | |
| Min. bend radius (mm) | Statics | 12.5 * cable diameter |
| Dynamics | 25 * cable diameter | |
| Drum length (KM) | - | 2 to 4 |
| Working temperature (℃) | - | -40 to +60 |
| Contact us for more details | ||
REMARKS
Detail requirements need to be sent to us for cable design and price calculation. Below requirements are a must:
A, Power transmission line voltage level
B, fiber count
C, Span or tensile strength
D, weather conditions
