FIBERFUTURE Single-mode FC/APC connector, designed for low reflectivity, suitable for telecommunications and data communication networks. Adopt 2.5mm ceramic pin and threaded metal locking structure to ensure stable connection. Angle polishing technology reduces signal attenuation, blue protective cap logo, support 900μm, 2mm or 3mm fiber diameter, to ensure efficient data transmission.
| Applicable connector type | FC/APC |
| Optical fiber type | SM |
| Test the wavelength | 1310nm~1550nm |
| Insertion loss | Typical value≤0.15, maximum≤0.30 |
| Return Loss | ≥60dB |
| Insert core diameter | ∮2.5mm |
| Insert core parameter | Aperture: 125.5+1/-0μm, Concentricity: ≤1.0μm |
| Durability | 1000 times plug |
| Suitable for optical cable diameter | ∮2.0mm, ∮3.0mm |
| Working temperature | -20℃to+70℃ |
| Storage temperature | -40℃to+85℃ |
