ADSS optical cable (also known as all-dielectric self-supporting optical cable) is a non-metallic optical cable composed of all-dielectric materials. It can withstand its own weight and external loads. It is commonly used in communication lines of overhead high-voltage transmission systems and can be used in In strong electricity environments such as power communications (such as railways), as well as in environments with long distance spans such as lightning-prone areas, crossing rivers, or complex terrain. Hunan GL Technology Co., Ltd is a self-supporting adss optical cable manufacturer that supports customization (number of optical fibers: 2~144 cores, span: 100~1000 meters). Please inquire about the price of ADSS optical cables. How much does a 24 core ADSS optical cable cost? Please call us quickly Get the latest quotes.
1. Light weight and small cable diameter reduce the impact of ice and wind and the load on towers and supports;
2. Large span, with the maximum span exceeding 1,000 meters;
3. Can be installed without interruption of power supply;
4. Life expectancy is greater than 30 years;
The design of adss optical cable fully considers the actual conditions of power lines and is suitable for different levels of high-voltage transmission lines. For power lines below 110kV, polyethylene (PE) sheaths can be used; for power lines above 110kV, the cable hanging point must be determined by calculating the electric field strength distribution and an anti-tracing (AT) outer sheath must be used.
Save money - with manufacturer direct pricing
Save time - with experienced team to get project done
Lead the industry - with the most cutting-edge products
